Total 26 products

  • DBA series Triplex Plunger Pump

    The DBA commercial crankshaft pump converts the rotational motion of a crankshaft into the reciprocating motion of a plunger through a connecting rod mechanism. In combination with one-way valves, it enables fluid pumping and pressure generation. This type of pump is widely used in applications such as household and commercial cleaning, municipal sanitation cleaning, pipeline unclogging, long-distance water transfer and irrigation, and high pressure misting.

    넶21 ¥ 0.00

  • DAC Type Wobble-plate Axial Pump

    Manifold: Brass forged
    Housing: Die-cast aluminum alloy, anodized
    Wobble Plate: Forged steel alloy
    Plunger: Ceramic coating, precision grinded
    Sealing: U type, high-low dual pressure packing
    Bearing: Dual thrust bearing
    Unloader: Integrated with manifold
    Unloader Port: Inlet 3/4" (BSP or NH), Outlet M22
    Oil Bath Capacity: 120ml
    Oil Type: 15W/40 Non-Detergent
    Water Inlet Pressure: 0-50psi/3.5bar
    Max Inlet Water Temp. ≤ 50°C/122°F

    넶23 ¥ 0.00

  • DBCL series Triplex Plunger Pump

    The DBCL is a commercial-grade triplex plunger pump featuring a forged brass head, porcelain-sprayed plungers, and a double sealing system. It distinguishes itself with integrated pressure regulation and a pressure switch, delivering stable performance within a flow range of 10-18 L/min and pressures up to 20.6 MPa, all while offering high cost-effectiveness.

    넶35 ¥ 0.00

  • DBC series Triplex Plunger Pump

    MANIFOLD: Forged brass
    CRANKCASE: Aluminum alloy, die-cast, anodized
    CRANKSHAFT: Steel alloy, forged, hardened, precision grinded
    CONNECTING ROD (18SERIES): Aluminum alloy Zinc alloy (optional)
    BEARING: Ball and needle bearing
    PLUNGER: Solid stainless steel, ceramic coating, precision grinded
    PLUNGER SEALS: Germany Parker, U type, duplex packing
    LUBRICATION: Splash type, oil type 15W-40
    UNLOADER (18 SERIES): Bolt on, internal bypass, trap type, built with detergent injector
    INLET: G 3/4"

    넶19 ¥ 0.00

  • DAA Type Swash Plate Axial Pump

    Manifold: Brass forged
    Housing: Die-cast aluminum alloy, anodized
    Wobble Plate: Forged steel alloy
    Plunger: Ceramic coating, precision grinded
    Sealing: U type, high-low dual pressure packing
    Bearing: Dual thrust bearing
    Unloader: Integrated with manifold
    Unloader Port: Inlet 3/4" (BSP or NH), Outlet M22
    Oil Bath Capacity: 150ml
    Oil Type: 15W/40 Non-Detergent
    Water Inlet Pressure: 0-50psi/3.5bar
    Max Inlet Water Temp. ≤ 50°C/122°F

    넶244 ¥ 0.00
